CSHNQ20k
CSHNQ20k
Custom 20khz Echo Sounder Transducer for Sonar
We independently developed acoustic transducer products cover a full range of hydrophones, transmitting transducers, transceiver transducers, sonar array transducers and ultrasonic transducers, covering overflow rings, flextensional and curved discs. and composite materials, etc., achieving full coverage from low to medium frequency to high frequency, from shallow water to 10,000-meter water depth, and can be widely used for listening and homing detection, communication networking, positioning and navigation, seabed surveying and mapping, forward-looking side scanning, industrial and medical ultrasound and other types of acoustic equipment.
Specification:
Model | CSHNQ20k (Depth transducer) |
|
resonant frequency | 20.1kHz | |
Working frequency | 20.1kHz | |
Static Capacitance | 14000～26000pf | |
Directivity | Transmitting : 21 ± 4 degrees
Receiving: ≥ 45 degrees | |
free field voltage sensitivity | ≥900μV/Pa | |
sound source level | ≥210dB | |
Working depth | 300m | |
Cable Specification | φ13.5 Core shielded cable | |
Weight | 53kg | |
| ||
