Custom 300Hz-10Khz Ultra-low Frequency Hydrophone Sound Source

Custom 300Hz-10Khz Ultra-low Frequency Hydrophone Sound Source

Specification:

1. Working frequency band: 0.3kHz~10kHz;

2. transmitting sound source level:

(1) 0.3kHz~1kHz≥160dB (maximum value not less than 180dB);

 (2) 1kHz ~ 2kHz≥170dB (maximum value not less than 185dB);

(3) 2kHz ~10kHz≥180dB.

3. Directivity

(1) Horizontal opening angle: horizontal omnidirectional;

(2) Vertical opening angle: ≥85°.

4. Main structure

(1) Size: ≤Ф280mm*550mm (diameter*height);

(2) Weight: ≤25kg (excluding cable);

(3) Can be suspended for use;

5. Electrical interface cable length: ≥30m;

6. Withstand voltage: ≥100m.
